SIEMENS ET 200SP, AI 8xRTDTC 2-Wire HF 6ES7134-6JF00-0CA1

About SIEMENS ET 200SP, AI 8xRTDTC 2-Wire HF 6ES7134-6JF00-0CA1

Brand Siemens Firmware versionV2.1STEP 7 TIA Portal configurable/integrated from versionV16, V17 / V18Model Name/Number6ES7134-6JF00-0CA1Product type designation AI 8xRTD/TC 2-wire HFSI MATIC ET 200SP, Analog input module, AI 8xRTD/TC 2-wire High Feature suitable for BU type A0, A1, Color code CC00, channel diagnostics, 16 bit, +/-0.1%

Siemens ET 200SP Analog Input Module AI 8xRTD/TC 2-wire HF

Part Number: 6ES7134-6JF00-0CA1

General Information

• Module Type: Analog input module, 8 channels, 2-wire RTD/TC High Feature

• Base Units Supported: BU type A0, A1

• Color Code: CC00

• Channel Diagnostics: Yes, 16-bit, 0.1%

• Firmware Version: V2.1 (FW update possible)

• I&M Data: Yes, I&M0 to I&M3

• Isochronous Mode: No

• Measuring Range Scalable: Yes

Engineering/Configuration

• STEP 7 TIA Portal: V16, V17 / V18

• STEP 7 Classic: V5.5 SP3 / SP4

• PCS 7: V8.1 SP1

• PROFIBUS GSD: Revision 3 and 5+

• PROFINET GSDML: V2.35

• CiR (Configuration in RUN): Reparameterization & Calibration possible

Supply Voltage

• Rated Value: 24 V DC

• Permissible Range: 19.2 28.8 V DC

• Reverse Polarity Protection: Yes

• Max Current Consumption: 35 mA

• Power Loss: Typ. 0.75 W

Analog Inputs

• Number of Inputs: 8

• Input Types: Voltage, Thermocouples (B, C, E, J, K, L, N, R, S, T, U, TXK), RTDs (Ni, Pt), Resistors

• Input Resistance: 1 M for all channels

• Constant Measurement Current (for RTDs): 2 mA

• Permissible Input Voltage (max): 30 V

• Measurement Principle: Integrating (Sigma-Delta)

• Resolution: 16-bit (including sign)

• Conversion Time: 18.75 180 ms per channel (depending on parameterization)

• Oversampling & Smoothing: 4 levels, parameterizable

Error & Accuracy

• Linearity Error: 0.01% (0.1% for RTDs & resistors)

• Temperature Error: 0.0009% / K (0.005% / K for thermocouples)

• Crosstalk: Min. -50 dB

• Repeat Accuracy: 0.05%

• Operational Error Limit: Voltage 0.1%, Resistance 0.1%

Diagnostics / Status

• Diagnostic Alarm: Yes

• Limit Value Alarm: Two upper & two lower per channel

• Wire-Break & Overflow/Underflow Monitoring: Yes, channel by channel

• LEDs:

  • PWR (Green)

  • Channel Status (Green)

  • Channel Diagnostics (Red)

  • Module Diagnostics (Green/Red DIAG)

Potential Separation & Isolation

• Between Channels: No

• Channels vs Backplane Bus: Yes

• Channels vs Electronics Power Supply: Yes

• Isolation Tested: 707 V DC

Cable Length

• Shielded: Max 200 m (50 m for thermocouples)

Ambient Conditions

• Operating Temperature:

  • Horizontal: -30 C to 60 C

  • Vertical: -30 C to 50 C

• Maximum Installation Altitude: 2,000 m above sea level

Dimensions & Weight

• Width: 15 mm

• Height: 73 mm

• Depth: 58 mm
