SIEMENS ET 200SP, DI 8x 24V DC SRC BA 6ES7131 6BF61 0AA0

The ET 200SP, DI 8x 24V DC SRC BA 6ES7131 6BF61 0AA0 is designed for industrial automation applications. Operating at a frequency of 50/60 Hertz (HZ), this product comes with a standard size and rack-mounting type in a sleek grey color. It is known for its high-quality performance and durability, backed by a 1-year warranty.

Siemens SIMATIC ET 200SP DI 8x24 VDC SRC BA

Digital Input Module 8 DI, 24 V DC, Sourcing (NPN)

Type 1 according to IEC 61131

General Information

• Product type: DI 8x24 VDC SRC BA

• Hardware functional status: FS02

• Firmware version: V0.0 (FW update not possible)

• Usable BaseUnits: BU type A0

• Module color code: CC02

• I&M data support: Yes (I&M0 to I&M3)

• Isochronous mode: No

• PROFINET support: Yes

• Engineering:

  • STEP 7 TIA Portal from V14

  • STEP 7 V5.5 SP3 / -

  • PROFIBUS: GSD Revision 3+

  • PROFINET: GSDML V2.3

Supply Voltage

• Rated value: 24 V DC

• Permissible range: 19.228.8 V DC

• Reverse polarity protection: Yes

Input Specifications

• Number of digital inputs: 8 (parameterizable)

• Input type: Sourcing (NPN)

• Input characteristic: IEC 61131, type 1

• Input voltage:

  • Signal "0": 30 V to -5 V (reference L+)

  • Signal "1": -11 V to -30 V (reference L+)

• Input current: typ. 6 mA for signal "1"

• Input delay (parameterizable): 0.05 / 0.1 / 0.4 / 0.8 / 1.6 / 3.2 / 12.8 / 20 ms (+ 30500 s depending on line length)

• Cable length:

  • Shielded: max. 1,000 m

  • Unshielded: max. 200 m

Encoder Support

• 2-wire sensor: Yes

• Max permissible quiescent current: 1.5 mA

Diagnostics / Status

• Diagnostic functions: Yes

• Diagnostic alarms: Yes

• Monitoring supply voltage: Parameterizable

• LED indicators:

  • Power (PWR) green

  • Channel status green

  • Module diagnostics green/red DIAG LED

• Potential separation:

  • Between channels: No

  • Between channels and backplane bus: Yes

  • Between channels and electronics power supply: No

• Isolation tested: 707 V DC

Power Consumption

• Rated current: 4.5 mA

• Max current: 53 mA

• Typical power loss: 1.5 W

Addressing

• Input address space per module: 1 byte

• Automatic mechanical coding: Type B

Environmental / Mechanical

• Operating temperature (horizontal): -30 C to 60 C

• Operating temperature (vertical): -30 C to 50 C

• Storage temperature: Not specified

• Installation altitude: max. 5,000 m above sea level

• Dimensions: W 15 mm H 73 mm D 58 mm

• Weight: 28 g
