The SIEMENS S7 1500 CPU 1515 2 PN is a high-quality industrial automation solution designed for efficient performance in various applications. With a powerful frequency of 50/60 Hertz (HZ), this CPU ensures reliable operation and seamless integration within standard industrial setups. Its standard size and sleek grey color make it suitable for diverse industrial environments. Backed by a 1-year warranty, this SIEMENS CPU guarantees durability, quality, and optimal functionality for industrial automation needs.

General Information

Product type designation: CPU 1515-2 PN
HW functional status: FS04
Firmware version: V4.0

• FW update possible: Yes

Product Function

• I&M data: Yes (I&M0 to I&M3)

• Isochronous mode: Yes; distributed & central

• SysLog: Yes

Engineering

• STEP 7 TIA Portal: V20 (FW V4.0) / V18 (FW V3.0) or higher

• Older versions configurable as: 6ES7515-2AM02-0AB0

Display

• Screen diagonal: 6.1 cm

Control Elements

• Number of keys: 8

• Mode buttons: 2

Supply Voltage

• Rated value (DC): 24 V

• Range: 19.2 V 28.8 V

• Reverse polarity protection: Yes

Mains Buffering

• Stored energy time: 5 ms

• Repeat rate min.: 1/s

Input Current

• Rated consumption: 0.65 A

• Max: 1.03 A

• Inrush current: 1.15 A

• It: 0.6 As

Power

• Infeed to backplane: 12 W

• Consumption from backplane: 6.2 W

• Power loss (typ.): 3.6 W

Memory

SIMATIC Memory Card

• Number of slots: 1

• Required: Yes

Work Memory

• Program: 1 MB

• Data: 4.5 MB

Load Memory

• Plug-in (max.): 32 GB

CPU Processing Times

• Bit operations: 6 ns

• Word operations: 7 ns

• Fixed point: 9 ns

• Floating point: 37 ns

CPU Blocks

• Total elements: 8,000 (OB, FB, FC, DB, UDT)

DB

• Range: 1 60,999

• Max size: 4.5 MB (64 KB for Absolute addressing DBs)

FB / FC / OB

• Number range: 0 65,535

• Max size: 1 MB

Counters / Timers

• S7 counters: 2,048

• S7 timers: 2,048

• IEC counters/timers: Limited only by memory

• Retentivity: Adjustable

Retentive Data

• Standard retentive area: 512 KB

• Extended retentive area: 4.5 MB (with PS 6 0W 24/48/60 V DC HF)

Address Area

• Max. IO modules: 8,192

• Inputs: 32 KB

• Outputs: 32 KB

• Subprocess images: Up to 32

Hardware Configuration

• Distributed IO systems: 64

• DP masters via CM: 8

• IO Controllers: 2 (integrated) + 8 via CM

Rack

• Modules per rack: 32

• Lines: 1

Time of Day

• Hardware clock

• Backup: 6 weeks

• Max deviation: 10 s/day (typical: 2 s)

Interfaces

PROFINET Interfaces: 2

Interface 1 (X1)

• RJ45 (2-port switch)

• IPv4, PROFINET IO Controller/Device, IRT, MRPD, MRP

• Web server: Yes

• Open IE communication: Yes (optional encryption)

Interface 2 (X2)

• RJ45 (single port)

• No IRT, no media redundancy

Web Server

• HTTP/HTTPS

• User pages

• Max sessions: 100

• Max HTTP calls: 4

OPC UA

• Client + Server supported

• Medium License required

• Full security policies

Diagnostics

• Diagnostic buffer: 3,200 entries (500 powerfail-proof)

• Traces: 4 (512 KB each)

Technology Objects

• Motion control supported

• Motion resources: 2,400

• Positioning axes: 11 (4 ms) / 20 (8 ms)

Ambient Conditions

• Operating temp. (horizontal): -30C to +60C

• Operating temp. (vertical): -30C to +40C

• Storage: -40C to +70C

• Altitude: Up to 5,000 m

Dimensions & Weight

• Width: 70 mm

• Height: 147 mm

• Depth: 129 mm

• Weight: approx. 456 g
