SIEMENS HMI 6AV2124-1DC01-0AX0

About SIEMENS HMI 6AV2124-1DC01-0AX0

Data Sheet 6AV2124-1DC01-0AX0

SIMATIC HMI KP400 Comfort

Comfort Panel, key operation, 4" widescreen TFT display, 16 million colors, PROFINET interface, MPI/PROFIBUS DP interface, 4 MB on figuration memory, Windows CE 6.0. Configurable from WinCC Comfort V11.

General Information

Product type designation: KP400 Comfort

Display

• Design of display: TFT

• Screen diagonal: 4.3 in

• Display width: 95 mm

• Display height: 53.8 mm

• Number of colors: 16,777,216

Resolution

• Horizontal: 480 pixel

• Vertical: 272 pixel

Backlighting

• MTBF (25 C): 80,000 h

• Backlight dimmable: Yes (0100%)

Control Elements

Keyboard

• Function keys: 8

• Function keys with LEDs: 8

• Keys with LED: Yes

• System keys: Yes

• Numeric keyboard: Yes

• Alphanumeric keyboard: Yes (mobile phone type)

Touch Operation

• Touch screen: No

Expansions

• DP Direct LEDs (F1Fx): 8

• Direct keys (F1Fx): 8

• Direct touch keys: 0

Mounting

• Mounting position: Vertical

• Wall/direct mounting: No

• Portrait format possible: No

• Landscape format possible: Yes

• Max tilt angle without ventilation: 35

Supply Voltage

• Type: DC

• Rated value: 24 V

• Range: 19.2 V to 28.8 V

Input Current

• Rated consumption: 0.13 A

• Starting current (It): 0.5 As

Power

• Active power input: 3.1 W

Processor & Memory

• Processor type: ARM

• Flash: Yes

• RAM: Yes

• User memory: 4 MB

Indicators

• Info LED: Yes

• Power LED: No

• Error LED: No

Acoustics

• Buzzer: Yes

• Speaker: No

Time of Day

• Hardware RTC: Yes

• Software clock: Yes

• Retentive: Yes (approx. 6 weeks)

• Synchronizable: Yes

Interfaces

• Industrial Ethernet: 1

• RS485: 1 (RS422/485 combined)

• RS422: 1

• RS232: 0

• USB interfaces: 1 (USB 2.0)

• USB Mini-B: 1 (5-pole)

• SD card slots: 2

• Software interfaces: No

Ethernet

• Status LEDs: 2

• Switch ports: 1 (No switch integrated)

Protocols

• PROFINET: Yes

• PROFINET IO: Yes

• IRT: No

• PROFIBUS: Yes

• EtherNet/IP: Yes

• MPI: Yes

Ethernet Protocols

TCP/IP, DHCP, SNMP, DCP, LLDP

Web Features

• HTTP: Yes

• HTTPS: No

• HTML: Yes

• XML: No

• CSS: Yes

• ActiveX: No

• JavaScript: Yes

• Java VM: No

Diagnostics

• Diagnostic info readable: Yes (S7 controller)

EMC

• EN 55011 Class A (industrial): Yes

• EN 55011 Class B (residential): No

Protection

• Front: IP65

• Rear: IP20

• NEMA 4 / 4X (front): Yes

Approvals

CE, cULus, RCM, KC

Hazardous Areas

• ATEX Zone 2/22
• IECEx Zone 2/22
• cULus Class I Zone 2
• FM Class I Division 2

Marine Approvals

GL, ABS, BV, DNV, LRS, NK

Ambient Conditions

Operation Vertical

• Min: 0 C

• Max: 50 C

Operation Max Tilt Angle

• Min: 0 C

• Max: 40 C

Portrait Format

• Vertical: 040 C

• Tilt angle: 035 C

Storage

• -20 C to 60 C

Humidity

• Max: 90% (No condensation)

Operating System

• Windows CE: Yes

• Proprietary OS: No

Configuration / Header

Message indicator, alarms, process values, recipe management

Configuration Software

• WinCC Comfort/Advanced/Professional (from V11)

• Not supported: STEP 7 Basic/Pro, WinCC flexible, WinCC Basic

Languages

• Online/runtime: 32

• Project languages: 32

WinCC (TIA Portal) Functionality

Libraries, Web browser, Pocket Word, Pocket Excel, PDF Viewer, Media Player, Sm@rtServer, Audit

Messages

• Alarm classes: 32

• Bit messages: 2,000

• Analog messages: 50

• Message buffer: 256 entries, retentive

Recipes

• Recipes: 100

• Records per recipe: 200

• Entries per record: 200

• Internal memory: 512 kB

• Expandable: Yes

Variables

• Per device: 1,024

• Per screen: 50

• Limit values, structures, arrays: Supported

Images

• Configurable images: 500

• Pop-ups, slide-ins, f(x) trends, PDF display, camera display: Yes

Archiving

• Archives: 10

• Entries per archive: 10,000

• Formats: CSV, TXT, RDB

• Storage: SD card, USB, Ethernet

Security

• User groups: 50

• User rights: 32

• Users: 50

• Password import/export: Yes

• SIMATIC Logon: Yes

Transfer

• MPI/PROFIBUS DP: Yes

• USB: Yes

• Ethernet: Yes

• External storage: Yes

Process Coupling

Supports S7-1200/1500/200/300/400, LOGO!, WINAC, SINUMERIK, SIMOTION, Allen Bradley, Mitsubishi, OMRON (LINK), Modicon, OPC UA Client/Server

Peripherals

• Printers: Yes

• Memory cards: MMC (up to 128 MB), SD (up to 2 GB)

• USB memory: Up to 16 GB

• Network camera: Yes

Mechanical Data

• Front width: 152 mm

• Front height: 188 mm

• Cutout: 136 172 mm

• Depth: 48 mm

Weight

• Without packaging: 0.8 kg

• With packaging: 0.9 kg
