SIMATIC HMI KTP400 Comfort 4" Widescreen Panel

Article No.: 6AV2124-2DC01-0AX0

General Information

• Product type: KTP400 Comfort

• Display type: TFT

• Screen size: 4.3" (95 mm 53.8 mm)

• Colors: 16.7 million

• Resolution: 480 272 pixels

• Backlighting MTBF: 80,000 h

• Backlight dimmable: 0100%

• Touch operation: Analog-resistive touchscreen

• Control keys:

  • 4 function keys with LEDs

  • Onscreen numeric & alphanumeric keyboard

• DP direct LEDs: 4

• Direct touch keys as S7 I/O: 32

Mounting

• Position: Vertical

• Portrait and landscape supported

• Max tilt without ventilation: 35

Power Supply

• Type: DC

• Rated voltage: 24 V

• Permissible range: 19.2 28.8 V

• Current consumption: 0.13 A

• Active power input: 3.1 W

Processor & Memory

• Processor: ARM

• Memory for user data: 4 MB (Flash + RAM)

Indicators & Acoustics

• Buzzer: Yes

• Speaker: No

• LEDs: No (Info/Power/Error)

Clock

• Hardware & software clock: Yes, retentive (~6 weeks), synchronizable

Interfaces

• Industrial Ethernet: 1 port

• RS-422 / RS-485: 1 combined port

• USB: 1 USB Mini B (2.0)

• SD card slots: 2

• Protocols: PROFINET, PROFIBUS, EtherNet/IP, MPI, TCP/IP, DHCP, SNMP, DCP, LLDP

WEB/Browser

• HTTP: Yes

• HTML/CSS/JavaScript: Yes

• HTTPS, XML, Java VM: No

Redundancy & Other Protocols

• Media redundancy MRP: No

• MODBUS: Yes

• CAN: No

Diagnostics & EMC

• Diagnostic info readable: S7 controller

• EMC emission limits: Class A (industrial areas)

• Protection class: Front IP65, Rear IP20

Certifications

• CE, cULus, RCM, KC

• Hazardous areas: ATEX Zone 2/22, IECEx Zone 2/22, FM Class I Division 2

• Marine approvals: GL, ABS, BV, DNV, LRS, NK

Ambient Conditions

• Operation temperature (vertical): 0 50 C

• Max tilt operation: 0 40 C

• Storage temperature: -20 60 C

• Max relative humidity: 90% (non-condensing)

Software & Configuration

• OS: Windows CE 6.0

• Configurable via: WinCC Comfort V11 / Advanced / Professional

• Languages: 32 online/runtime, 32 project languages

• Libraries & applications: Web browser, Pocket Word/Excel, PDF Viewer, Media Player, Sm@rtServer, WinCC Audit

Messages & Alarms

• Alarm classes: 32

• Bit messages: 2,000

• Analog messages: 50

• Message buffer: 256 entries, retentive

• Recipe management: 100 recipes, 200 records/recipe, expandable

Variables & Screens

• Variables per device: 1,024

• Variables per screen: 50

• Configurable images: 500

• Objects per image: 50

• Complex image objects per screen: 5

Archiving

• Archives per device: 10

• Entries per archive: 10,000

• Memory location: SD card, USB, Ethernet

• Formats: CSV, TXT, RDB

Security

• Users: 50

• User groups: 50

• User rights: 32

• SIMATIC Logon & password export/import: Yes

Peripherals / Storage

• MM card: Up to 128 MB

• SD card: Up to 2 GB

• USB memory: Up to 16 GB (USB stick), Up to 8 GB (HMI USB stick)

• Printer & network camera support: Yes

Mechanics / Dimensions

• Front material: Plastic

• Width Height (front): 140 116 mm

• Mounting cutout: 124 100 mm

• Depth: 48 mm

• Weight: 0.6 kg (0.7 kg with packaging)
