About SIEMENS HMI 6AV2128-3GB06-0AX1

Display Size7 Inch Mounting Type Panel Mount Phase Three Phase Resolution 800 x 480 Pixels BRAND SIEMENS SIMATIC HMI MTP700,Unified Comfort Panel,touch operation,7" widescreen TFT display,16 million colors,PROFINET interface,configurable as of WinCC Unified Comfort V16,contains open-source software,which is provided free of charge see enclosed DVD

Data Sheet 6AV2128-3GB06-0AX1

SIMATIC HMI MTP700 Unified Comfort Panel

7" widescreen TFT display, 16 million colors, PROFINET interface, WinCC Unified Comfort V16 or later.

General Information

• Product type: MTP700 Unified Comfort

• Display type: TFT

• Screen size: 7 inch

• Display resolution: 800 480 pixels

• Display dimensions: 152.4 mm 91.4 mm

• Colors: 16,777,216

• Backlight MTBF (25 C): 50,000 h

• Backlight dimming: 5100 %

Operation

• Touch screen: Yes

• Multi-touch: Yes

• Onscreen keyboards: Numeric, Alphanumeric

Mounting

• Mounting position: Vertical

• Portrait mode: Yes

• Landscape mode: Yes

• Max tilt angle without ventilation: 35

Electrical Data

• Supply voltage: 24 V DC

• Voltage range: 19.2 28.8 V

• Rated current consumption: 0.45 A

• Max current consumption: 1 A

• Inrush current (It): 0.5 As

Memory

• Flash: Yes

• RAM: Yes

Acoustics

• Buzzer: Yes

• Speaker: No

Clock

• Real-time hardware clock: Yes

• Retentive backup: ~6 weeks

• Synchronizable: Yes

Interfaces

• Ethernet ports: 2 (switch) + 1 independent

• RS-485 / RS-422: 1 combined

• USB ports: 4 USB 3.1 (Type A)

• SD card slots: 2

Ethernet & Protocols

• PROFINET: Yes

• TCP/IP, DHCP, SNMP, DCP, LLDP: Supported

• Media Redundancy (MRP): Yes

Protection

• Front: IP65

• Rear: IP20

• NEMA: Type 4X / 12 (front)

Certifications

• CE, UKCA, cULus, RCM, KC, EAC, CCC: Yes

• Siemens Eco Profile: Yes

Environmental Data

• Indoor use only

• Operating temperature:

  • Vertical: 0 50 C

  • Tilted: 0 40 C

  • Portrait: 0 40 C

  • Portrait tilted: 0 35 C

• Storage temp: 20 60 C

• Humidity: Max 90% (no condensation)

Hazardous Area Approvals

• ATEX Zone 2 / 22: Yes

• IECEx Zone 2 / 22: Yes

• cULus Class I & II: Yes

• FM Class I & II: Yes

Marine Approvals

• DNV, ABS, BV, KRS, LRS, NK, CCS: Yes

Software / Functions (WinCC Unified)

• Runtime languages: 32

• Project languages: 32

• Built-in apps: Writer, Calc, Web Browser, PDF Viewer, Media Player

• Sm@rtServer: Yes

• WinCC Audit: Yes

• Unified Collaboration: Yes

• JavaScript support: Yes

• VB Script: No

Alarms & Messaging

• Alarm classes: 32

• Bit messages: 9000

• Analog messages: 300

• Message length: 512 characters

• Process values per message: 10

• Retentive alarm buffer: Yes

Recipes

• Parameter types: 750

• Sets per type: 2000

• Entries per set: 1000

• Internal memory: 12 MB

• Expandable: Yes

Variables / Screens

• Variables per device: 8000

• Variables per screen: 600

• Configurable screens: 1200

• Image objects: 800 per screen

• Complex objects per screen: 40

Archiving

• Archives: 50 per device

• Entries per archive: 500,000

• Types: Sequential, Short-term

• Storage: SD card, USB (Ethernet: No)

Security

• Roles: 50

• Function rights: 20

• Users: 200

• Central user administration: Yes (WinCC V17+)

Process Coupling

• S7-1200 / S7-1500: Yes

• S7-300 / S7-400: Yes

• LOGO! (from V20): Yes

• OPC UA Client/Server: Yes

Peripherals

• Printer: Yes

• Barcode reader: Yes

• SD card: Yes

• USB memory / sticks: Yes

• Network camera: No

Mechanical Data

• Front material: Aluminum

• Front width: 214 mm

• Front height: 158 mm

• Cutout size: 198.3 142 mm

• Depth: 63.6 mm

• Weight: 1.4 kg
