Siemens PLC IO Module ET200S 6ES7138-4FB04-0AB0

About Siemens PLC IO Module ET200S 6ES7138-4FB04-0AB0

SIMATIC DP, Electronics module for ET 200S, 4 F-DO PROFIsafe, 24 V DC/2 A, 30 mm overall width, up to PL E (ISO 13849), up to SIL 3 (IEC 61508), can also be used in PROFINET configuration with IM 151-3 HF

Siemens ET 200S F-DO 4x Transistor PROFIsafe Module

Part Number: 6ES7138-4FB04-0AB0

General Information

• Module Type: Electronics module for ET 200S, 4 F-DO

• Function: PROFIsafe, 24 V DC / 2 A, up to PL E (ISO 13849), up to SIL 3 (IEC 61508)

• Overall Width: 30 mm

• Compatibility: Can be used in PROFINET configuration with IM 151-3 HF

Supply Voltage

• Rated Value: 24 V DC

• Reverse Polarity Protection: No

• Input Current:

  • From load voltage L+ (no load), typ. 100 mA

  • From backplane bus 3.3 V DC, max. 28 mA

• Power Loss: Typ. 3.5 W

Digital Outputs

• Type: Transistor

• Number of Outputs: 4

• Short-Circuit Protection: Yes

• Inductive Shutdown Voltage Limitation: Typ. -47 V

• Controlling a Digital Input: No

Switching & Load Capacity

• Max Lamp Load: 10 W

• Load Resistance: 12 1 k

• Output Voltage:

  • Signal 1: Min L+ (-2 V), Voltage drop: Max 0.5 V

• Output Current:

  • Signal 1 rated: 2 A

  • Signal 1 range: 20 mA 2.4 A

  • Signal 0 residual current: Max 0.5 mA

• Parallel Switching: Not supported

• Switching Frequency:

  • Resistive Load: Max 30 Hz

  • Inductive Load: Max 0.1 Hz

  • Lamp Load: Max 10 Hz

• Total Module Current: Max 6 A (derating with temperature)

Cable Length

• Shielded / Unshielded: Max 500 m

Diagnostics & Status

• Diagnostics Function: Yes

• Wire-Break Detection: Yes

• Short-Circuit Detection: Yes

• LEDs:

  • Group Error SF (Red)

  • Status Indicator Digital Output (Green)

Potential Separation

• Between Channels: No

• Between Channels & Backplane Bus: Yes

• Between Channels & L+: No

Safety & Standards

• Highest Safety Class: EN 954-4

• Performance Level: PL E (ISO 13849-1)

• SIL: SIL 3 (IEC 61508)

Dimensions & Weight

• Width: 30 mm

• Height: 81 mm

• Depth: 52 mm

• Weight: 85 g
