SIEMENS V90 SERVO MOTOR 1FL6094-1AC61-2AA1

About SIEMENS V90 SERVO MOTOR 1FL6094-1AC61-2AA1

SIMOTICS S-1FL6-1FL6 Operating voltage 3AC 400 V Pn=5 kW; Nn=2000 rpm M0=30 Nm; MN=23.9 Nm Shaft height 90 mm, with angle plug; incremental encoder 2500 incr./rev. with feather key, tolerance without holding brake Degree of protection IP65 with sealing ring compatible with the converters SINAMICS V70 & V90

Engineering Data

• Rated Speed: 2,000 rpm

• Rated Torque (100 K): 23.90 Nm

• Rated Current: 12.6 A

• Rated Power: 5.00 kW / 6.80 hp

• Max Speed: 2,500 rpm

• Maximum Torque: 70.00 Nm

• Max Current: 36.9 A

• Static Torque: 30.00 Nm

• Moment of Inertia: 90.8 kgcm

Physical Constants

• Torque Constant: 2.00 Nm/A

• Thermal Class: B (130 C)

• Net Weight: 24.4 kg

Ambient Conditions

• Operating Temperature: 0 40 C

• Maximum Relative Humidity: 90 % RH (no condensation at 30 C)

Standards

• Compliance: CE, EAC

Mechanical Data

• Motor Type: High Inertia, Permanent-Magnet Synchronous Motor

• Shaft Height: 90 mm

• Encoder System: Incremental TTL, 2,500 S/R (13 bit)

• Cooling: Natural

• Shaft End: Feather key

• Radial Runout Tolerance: Class N

• Vibration Severity Grade: Grade A

• Degree of Protection: IP65

• Design: Code I IM B5 (IM V1, IM V3)

• Connection Type: Angular connector (rotatable)
