About SIEMENS PLC MODULES 6ES7322-1HF01-0AA0

Siemens 6ES7322-1HF01-0AA0 Digital Input Module

Product Type: Digital Input Module
Series: SIMATIC S7-300
Brand: Siemens

The Siemens 6ES7322-1HF01-0AA0 is a digital input module designed for the SIMATIC S7-300 PLC system. It receives digital (ON/OFF) signals from field devices such as sensors, switches, and pushbuttons, converting them into data the PLC can process.

Key Features:

• 16 Digital Input Channels: Supports binary input signals.

• Operating Voltage: 24V DC standard for industrial applications.

• Fast Response Time: Suitable for high-speed digital signal detection.

• LED Indicators: Individual LEDs for each channel to monitor input status.

• Wide Voltage Range: Ensures compatibility with multiple field devices.

• Modular Design: Fully compatible with the S7-300 modular PLC system.

• Diagnostics: Built-in diagnostics for fault detection and easy troubleshooting.

• Configuration: Easily configured using Siemens STEP 7 software.

SIMATIC S7-300 SM 322

Article No.: 6ES7322-1HF01-0AA0

Digital Output Module 8 DO (Relay), 24 V DC / 230 V AC, 2 A, isolated, 1x 20-pole

Supply Voltage

• Rated Value (DC): 24 V

• Input Current:

  • From L+: Max. 160 mA

  • From backplane bus 5 V DC: Max. 40 mA

• Power Loss: Typ. 3.2 W

Digital Outputs

• Number of Outputs: 8 (Relay)

• Short-Circuit Protection: No

• Controlling a Digital Input: Yes

• Switching Capacity:

  • Lamp load: Max. 50 W

  • Low energy/fluorescent lamps (electronic): 10 58 W

  • Fluorescent tubes, conventional: 1 58 W

  • Fluorescent tubes, uncompensated: 10 58 W

• Output Current (Signal 1): Rated 2 A, Minimum 5 mA

• Parallel Switching:

  • For uprating: No

  • For redundant control: Yes

• Switching Frequency:

  • Resistive load: Max. 2 Hz

  • Inductive load: Max. 0.5 Hz

  • IEC 60947-5-1 (DC13/AC15): Max. 0.5 Hz

  • Lamp load: Max. 2 Hz

  • Mechanical: Max. 10 Hz

Relay Outputs

• Rated Coil Voltage L+: 24 V DC, 110 mA

• Contact Connection (Internal): Yes, SIOV-CU4032 K275G

• Number of Operating Cycles:

  • 230 V AC: 100,000

  • 120 V AC: 200,000

  • 24 V DC: 300,000 (at 2 A)

• Switching Capacity of Contacts:

  • Inductive load: Max. 2 A

  • Resistive load: Max. 2 A

  • Thermal continuous current: Max. 3 A

Cable Length

• Shielded: Max. 1000 m

• Unshielded: Max. 600 m

Diagnostics / Status

• Alarms: No

• Diagnostics Function: No

• Diagnostics Indication LED: Status indicator digital output (green)

Potential Separation & Isolation

• Digital Outputs:

  • Between channels: Yes

  • Between channels (in groups of 2): Yes

  • Between channels and backplane bus: Optocoupler

• Isolation Tested: 1500 V AC

Connection & Mechanical Data

• Required Front Connector: 20-pin

• Dimensions (W H D): 40 125 120 mm

• Weight: Approx. 190 g
