SINAMICS G120X Rated power: 22 kW At 110% 60s, 100% 240 s Unfiltered 380-480 V 3 AC +10/-20% 47-63 Hz Ambient temperature -20 to +45 Degree C Size: FSD Degree of protection IP20 / UL open type painting 3C2 with Basic Operator Panel Without IO expansion Fieldbus integrated: PROFINET PN, Ethernet IP

Data Sheet SINAMICS G120X

Article No.: 6SL3220-2YE32-0UF0

Technical data may change. Values may differ from rating plate.

General Information

Rated Data

Input

• Phases: 3 AC

• Line voltage: 380 480 V (+10% / -20%)

• Line frequency: 47 63 Hz

• Rated voltage: 400 V (IEC) / 480 V (NEC)

• Rated current (LO): 42 A (IEC), 37 A (NEC)

• Rated current (HO): 38 A (IEC), 35 A (NEC)

Output

• Phases: 3 AC

• Rated voltage: 400 V (IEC) / 480 V (NEC)

• Rated power (LO): 22 kW / 30 hp

• Rated power (HO): 18.5 kW / 25 hp

• Rated current (LO): 45 A (IEC), 40 A (NEC)

• Rated current (HO): 38 A (IEC), 34 A (NEC)

• Rated current (IN): 47 A

• Max. output current: 61 A

• Pulse frequency: 4 kHz

• Output frequency (vector): 0 200 Hz

• Output frequency (V/f): 0 550 Hz

Overload Capacity

• LO: 110% for 60 s (every 300 s)

• HO: 150% for 60 s (every 600 s)

General Technical Specifications

• Power factor : 0.90 0.95

• cos : 0.99

• Efficiency: 0.97

• Sound pressure level: 70 dB (1 m)

• Power loss: 0.732 kW

• Filter class: Unfiltered

• STO (Safe Torque Off): Not available

Communication

• Supported: PROFINET, EtherNet/IP

Inputs / Outputs

Standard Digital Inputs

• Quantity: 6

• Threshold (01): 11 V

• Threshold (10): 5 V

• Max inrush current: 15 mA

Fail-safe Digital Inputs

• Quantity: 1

Digital Outputs

• Relay outputs: 2

• Load: 30 V DC / 5 A

• Transistor outputs: None

Analog/Digital Inputs

• Quantity: 2 (Differential)

• Resolution: 10 bit

• Digital threshold:

  • 01: 4 V

  • 10: 1.6 V

Analog Output

• Quantity: 1 (Non-isolated)**

PTC/KTY Interface

• Supported sensors: PTC, KTY, Thermo-Click

• Accuracy: 5C

Closed-loop Control Methods

• V/f linear / square-law / parameterizable

• V/f with FCC

• V/f ECO

• Sensorless vector control

• Not supported: Encoder vector control, torque control

Ambient Conditions

• Board coating: Class 3C2

• Cooling: Integrated fan

• Air requirement: 0.055 m/s

• Altitude: 0 1000 m

• Operating temperature: -20 45C

• Transport temperature: -40 70C

• Storage temperature: -25 55C

• Humidity: 95% max (no condensation/icing)

Connections

Signal Cable

• Cross-section: 0.15 1.50 mm (AWG 2416)

Line Side (Input)

• Terminal type: Screw

• Cross-section: 10 35 mm (AWG 82)

Motor Side (Output)

• Terminal type: Screw

• Cross-section: 10 35 mm (AWG 82)

DC Link

• PE: Screw terminals

Max Motor Cable Length

• Shielded: 200 m

• Unshielded: 300 m

Mechanical Data

• Protection: IP20 / UL open type

• Frame size: FSD

• Weight: 17 kg

• Dimensions:

  • Width: 200 mm

  • Height: 472 mm

  • Depth: 248 mm

Standards & Approvals

• UL, cUL, CE, RCM, EAC, KCC, SEMI F47, REACH

• CE: EMC Directive 2004/108/EC, Low Voltage Directive 2006/95/EC

• Efficiency class: IE2

Operator Panel BOP-2

Display

• LCD, monochrome

• Protection: IP55 / UL Type 12

Mechanical

• Weight: 0.140 kg

• Dimensions:

  • W: 70 mm

  • H: 106.85 mm

  • D: 19.60 mm

Temperature

• Operation: 0 50C

• Storage/Transport: -40 70C
