Siemens 6ES7131-4BD01-0AA0 Electronic Module for ET 200S

The Siemens 6ES7131-4BD01-0AA0 is an electronic module designed for the ET 200S distributed I/O system in SIMATIC DP (Distributed Periphery) networks. This module serves as an essential part of the ET 200S system, enabling communication and control within industrial automation systems, allowing for efficient data exchange between I/O devices and a central PLC (Programmable Logic Controller).

Key Features of the 6ES7131-4BD01-0AA0 (Electronic Module for ET 200S):

• Communication and Control: The electronic module is responsible for managing the communication between the ET 200S I/O modules and the central PLC using industrial communication protocols like Profibus DP or Profinet.

• Data Exchange: It ensures reliable and fast data transfer, which is essential for real-time control and monitoring in industrial environments. This is critical for applications requiring fast response times, such as machine control, process automation, and robotics.

• Modular Design: The ET 200S system is designed to be modular, and this electronic module is part of a scalable system where additional I/O modules can be added as required. This makes it adaptable to a wide range of applications and system sizes.

• Diagnostics and Monitoring: This module includes diagnostic features that help monitor the status of the system, making it easier to detect and troubleshoot any issues, ensuring high system uptime.

• Compact and Flexible: The module is compact in design, allowing easy integration into control cabinets or distributed installations. Its flexible integration with Siemens PLCs enhances its ability to fit into a variety of automation systems.

Applications:

• Distributed I/O Systems: The module is ideal for use in systems where I/O points are spread out across large installations, such as production lines, manufacturing facilities, or packaging systems.

• Industrial Automation: It is used for controlling and monitoring industrial machines and processes that require reliable communication between distributed devices and the central controller.

• Flexible and Scalable Control Systems: Perfect for applications that require a scalable solution, where I/O points might be added or changed as the system grows.

The 6ES7131-4BD01-0AA0 electronic module is a critical component for ensuring efficient communication, data transfer, and diagnostics in ET 200S distributed I/O systems, making it an essential part of industrial automation networks.

SIMATIC ET 200S SM 4DI Standard Module

Article No.: 6ES7131-4BD01-0AA0
Spare Part 5 electronic modules per packing unit

General Information

• Module type: 4 digital inputs (DI), standard 24 V DC

• Width: 15 mm

• Packing unit: 5 modules

• Supply voltage: 24 V DC (from power module)

• Reverse polarity protection: Yes

Input Current

• From supply voltage L+: Dependent on encoder

• From backplane bus (3.3 V DC): Max. 10 mA

Encoder Supply

• Type of output voltage: Min. L+ (-0.5 V) under load

• Output current:

  • Rated value: 500 mA

  • Permissible range: 0 500 mA

Power Loss

• Typical: 0.7 W

Address Area

• Per module: Max. 1 byte

• With packing: 4 bit

Digital Inputs

• Number of inputs: 4

• Input type: IEC 61131 Type 1

• Rated voltage: 24 V DC

• Signal levels:

  • "0": -30 +5 V

  • "1": +15 +30 V

• Input current (typical at 24 V): 7 mA

• Input delay:

  • "0 1": 2 4.5 ms (typ. 3 ms)

  • "1 0": 2 4.5 ms (typ. 3 ms)

Cable Length

• Shielded: Max. 1,000 m

• Unshielded: Max. 600 m

Encoder

• Connectable: 2-wire sensor

• Max. quiescent current: 1.5 mA

Diagnostics / Status

• LED indicators:

  • Group error SF (red): No

  • Status digital input (green): Yes, per channel

• Diagnostics function: No

Parameter

• Remark size: 1 byte

Potential Separation

• Between channels: No

• Between channels and backplane bus: Yes

• Isolation tested: 500 V DC

Mechanical Data

• Width Height Depth: 15 81 52 mm

• Weight: 35 g
