Siemens 6ES7134-4GB11-0AB0 Electronics Module F for ET 200S

The Siemens 6ES7134-4GB11-0AB0 is an Electronics Module F for the ET 200S distributed I/O system, designed for use in SIMATIC DP (Distributed Periphery) networks. This module is an integral part of the ET 200S system, which is used for expanding I/O capabilities in industrial automation systems while offering flexibility and scalability.

Key Features of the 6ES7134-4GB11-0AB0 (Electronics Module F for ET 200S):

• Electronics Module: Acts as a central component in the ET 200S system, providing communication and control for the I/O modules in the system.

• Communication Interface: Allows seamless communication between the ET 200S I/O modules and the central PLC controller, typically using Profibus DP or Profinet communication protocols.

• Modular and Scalable: The ET 200S system is designed for scalability, allowing for easy expansion with additional I/O modules, making it suitable for applications of various sizes and complexities.

• High-Speed Data Transfer: Supports high-speed communication for real-time data exchange, critical for applications requiring precise and timely control.

• Diagnostic and Monitoring: Provides diagnostic capabilities essential for identifying and troubleshooting issues in the system, improving reliability and minimizing downtime.

• Compact and Flexible Design: The ET 200S system is compact, making it easy to integrate into control panels and small control cabinets in space-constrained environments.

Applications:

• Distributed I/O Systems: Used in large-scale distributed control systems where I/O modules are spread across various locations.

• Manufacturing Automation: Suitable for controlling processes in industries such as automotive, packaging, and production lines, where flexibility and modularity are essential.

• Flexible Networked Systems: Ideal for applications where the automation system needs to be networked with other equipment or PLCs, enabling easy integration into complex control networks.

The 6ES7134-4GB11-0AB0 Electronics Module F for the ET 200S distributed I/O system is designed to enhance the flexibility, scalability, and communication capabilities of Siemens automation systems, enabling efficient and reliable control of industrial processes.

General Information

• Product: Electronics module for ET 200S

• Type: 2 AI Standard, I-4DMU

• Width: 15 mm

• Input ranges:

  • 20 mA, 50

  • 420 mA, 50

• Cycle time: 65 ms/channel

• SF LED: Indicates group fault

Supply Voltage

• Load voltage L+: 24 V DC (from power module)

Input Current

• From L+ (without load): Max 30 mA

• From backplane bus 3.3 V DC: Max 10 mA

Power Loss

• Typical: 0.6 W

Address Area

• Max address space per module: 4 bytes

Analog Inputs

• Number of inputs: 2

• Permissible input current: Max 40 mA (destruction limit)

• Measurement principle: Integrating

• Resolution (bit including sign):

  • 20 mA: 14 bit

  • 420 mA: 13 bit

• Integration time: 16.7 / 20 ms

• Conversion time per channel: 65 ms

• Interference suppression: 50 / 60 Hz

• Smoothing of measured values: Yes, 4 stages via digital filtering

  • None: 1x cycle time

  • Low: 4x cycle time

  • Medium: 32x cycle time

  • High: 64x cycle time

Accuracy

• Operational error limit (overall temperature): 0.6% of input range

• Basic error limit (25 C): 0.4% of input range

Diagnostics / Status

• Wire-break detection: Yes (420 mA only)

• Group error: Yes

• Overflow/underflow: Yes

• LED indicator: SF (red)

Parameters

• 4-byte parameter

• Wire break / group diagnostics / overflow: Enable/disable

Potential Separation

• Between channels: No

• Between channels & backplane bus: Yes

• Between channels & L+: No

Isolation

• Tested: 500 V DC

Dimensions

• Width: 15 mm

• Height: 81 mm

• Depth: 52 mm

Weight

• Approx. 40 g
