About SIMATIC S7-1200, Analog output, SB 1232, 1 AO, 6ES7232-4HA30-0XB0

Communication Protocols RS232 Mounting Type DIN Rail Pulse Transmission Output PROFINET Manufacturer Series S7 1200 Output Type Analog SIMATIC S7-1200, Analog output, SB 1232, 1 AO, +/-10 V DC (12 bit resol.) or 0-20mA (11 bit resol.)siemens expansion module

SIMATIC S7-1200 Analog Output Module SB 1232

Part Number: 6ES7232-4HA30-0XB0
Type: AQ 1x12 bit
Output: 1 AO, 10 V DC (12-bit) or 020 mA (11-bit)

General Information

• Product type designation: SB 1232, AQ 1x12 bit

• Input current from backplane bus 5 V DC: typ. 15 mA

• Supply current for transmitters: max. 25 mA

• Power loss (typical): 1.5 W

Analog Inputs / Outputs

• Analog inputs: 0

• Analog outputs: 1

Cycle Time (all channels):

• Voltage: 300 s (R), 750 s (1 F)

• Current: 600 s (1 mH), 2 ms (10 mH)

Output Ranges:

• Voltage: -10 V to +10 V

• Current: 020 mA

Load Impedance:

• Voltage output: min. 1000

• Current output: max. 600

Cable Length:

• Shielded, twisted pair: max. 100 m

Analog Value Generation: Differential conversion

Resolution:

• Voltage: 12-bit including sign

Temperature Error:

• 0.5% at 25 C

• 1% up to 55 C

Diagnostics / Status

• Alarms: Yes

• Diagnostics function: Yes

• LED indication for output status: Yes

Standards & Approvals

• CE, CSA, UL, cULus, FM, RCM, KC

• Marine approval: Yes

Ambient Conditions

• Free fall: 0.3 m, 5 times (in packaging)

• Operating temperature: -20 C to 60 C (horizontal) / -20 C to 50 C (vertical)

• Storage/transport temperature: -40 C to 70 C

• Air pressure (storage/transport): 6601080 hPa

• Relative humidity: max. 95% at 25 C without condensation

• Pollutant limits: SO < 0.5 ppm, HS < 0.1 ppm, RH < 60%

Mechanics

• Enclosure material: Plastic (front)

• Dimensions: W 38 mm H 62 mm D 21 mm

• Weight: approx. 40 g
