SIMATIC S7-1500T, CPU 1516T-3 6ES7516-3TN00-0AB0 About

Article Number (Market Facing Number) 6ES7516-3TN00-0AB0 Product Description SIMATIC S7-1500T, CPU 1516T-3 PN/DP, central processing unit with work memory 3 MB for program and 7.5 MB for data, 1st interface: PROFINET IRT with 2-port switch, 2nd interface, Ethernet, 3rd interface, PROFIBUS, 6 ns bit performance, SIMATIC Memory Card required Product family CPU 1516T-3 PN/DP Product Lifecycle (PLM) PM300: Active Product

Siemens SIMATIC S7-1500T CPU 1516T-3 PN/DP

Product Type: CPU 1516T-3 PN/DP
Work Memory: 3 MB program / 7.5 MB data
Interfaces:

• PROFINET IRT with 2-port switch

• Ethernet

• PROFIBUS
  Bit Performance: 6 ns
  SIMATIC Memory Card: Required

General Information

• HW Functional Status: FS11

• Firmware Version: V3.1 (FW update possible)

• Product Functions: I&M0 to I&M3, Isochronous mode, SysLog

• Engineering: STEP 7 TIA Portal V19+ (FW V3.1) / V15+ (FW V2.5)

Display & Controls

• Screen Diagonal: 6.1 cm

• Keys: 6

• Mode Selector Switch: 1

Supply & Power

• Rated DC Voltage: 24 V (range 19.2 28.8 V)

• Reverse Polarity Protection: Yes

• Infeed Power to Backplane Bus: 12 W

• Power Consumption (backplane): 30 W

• Power Loss (typical): 24 W

• Current Consumption: Rated 1.2 A, Max 1.5 A

• Inrush Current: Max 1.9 A

Memory

• SIMATIC Memory Card Slots: 1 (required)

• Load Memory: Max. 32 GB

• Flags: Max 16 KB

• Clock Memories: 8 bits

• Retentive Data Area: Max 512 KB (standard), 7.5 MB (extended)

CPU Performance

• Bit Operations: 6 ns

• Word Operations: 7 ns

• Fixed Point Arithmetic: 9 ns

• Floating Point Arithmetic: 37 ns

• DBs: 159,999 user, 60,00060,999 SFC 86, Max size 7.5 MB

• OBs, FBs, FCs: Max size 1 MB

• Free Cycle OBs: 100

I/O & Hardware Configuration

• Max I/O Modules: 8,192

• Integrated DP Master: 1

• Integrated I/O Controllers: 2

• Max Modules per Rack: 32

• Distributed I/O Systems: 64

Interfaces

1. PROFINET (X1)

• 2 ports, integrated switch

• IPv4, PROFINET IO Controller/Device, Web server, IRT, PROFIenergy

• Max connectable IO Devices: 256 (RT), 64 (IRT)

2. PROFINET (X2)

• 1 port, no switch

• Max connectable IO Devices: 32

3. RS-485 (X3)

• PROFIBUS DP Master, max 48 connections, max 125 DP devices

Ethernet Features

• 100 Mbps, autonegotiation, autocrossing, industrial LED indicators

• Media redundancy: MRP / MRPD

• Max simultaneous connections: 256

• S7 routing paths: 16

Communication Protocols

• PROFINET, PROFIBUS, MODBUS TCP

• OPC UA Server & Client

• Web server: HTTP/HTTPS, max 200 sessions

• Open IE, TCP/IP, ISO-on-TCP, UDP, DHCP, DNS, SNMP, LLDP

Motion Control & Technology Objects

• Motion Control resources: 6,400

• Positioning axes: 55 (4 ms cycle), 80 (8 ms cycle)

• Extended Motion Control resources: 192

• PID Controllers: PID_Compact, PID_3Step, PID_Temp

• High-speed counters: Yes

Diagnostics & Forcing

• RUN/STOP, ERROR, MAINT LEDs

• Connection LINK TX/RX LED

• Diagnostic buffer: 3,200 entries (500 powerfail-proof)

• Configurable traces: 4 (512 KB each)

• Forcing of I/O variables: Max 200

Programming

• Languages: LAD, FBD, STL, SCL, CFC, GRAPH

• User program protection: Yes

• Block protection: Yes

• Cycle time monitoring: Adjustable

Ambient Conditions

• Operating Temperature: Horizontal 060 C, Vertical 040 C

• Storage/Transport Temperature: -4070 C

• Max Installation Altitude: 5,000 m (restrictions above 2,000 m)

Dimensions & Weight

• Width: 175 mm

• Height: 147 mm

• Depth: 129 mm

• Weight: ~1,929 g
