About SINAMICS V20 6SL3210-5BE25-5UV0

The SINAMICS V20 6SL3210-5BE25-5UV0 is a top-notch industrial drive with a rated voltage of 380-480 Volt. Its compact design with dimensions of 184x182x169 mm and a sleek grey powder-coated finish not only saves space but also elevates the aesthetics of any industrial setup. This V/F control system offers precise control and reliable performance. With a protection level of IP20, it ensures the safety of your equipment. The digital display makes it user-friendly and easy to operate. Made of durable PVC material, this drive comes with a one-year warranty, guaranteeing quality and peace of mind.

SINAMICS V20

Article No.: 6SL3210-5BE25-5UV0

Rated Data

Input:

• Phases: 3 AC

• Line Voltage: 380 480 V (-15% +10%)

• Line Frequency: 47 63 Hz

Output:

• Phases: 3 AC

• Rated Voltage: 400 V IEC / 480 V NEC

• Rated Power LO / HO: 5.5 kW / 7.5 hp

• Rated Current LO / HO: 12.5 A / 11 A

• Rated Current IN: 12.5 A

• Pulse Frequency: 4 kHz

• Output Frequency: 0 550 Hz

Overload Capability

• Low Overload (LO): 110% for 60 s (300 s cycle)

• High Overload (HO): 150% for 60 s (300 s cycle)

General Technical Specifications

• Power Factor : 0.72

• Offset Factor cos : 0.95

• Efficiency : 0.98

• Filter Class: Unfiltered

Communication

• USS, Modbus RTU

Inputs / Outputs

• Standard Digital Inputs: 4

• Digital Outputs: 1 relay, 1 transistor

• Analog Inputs: 2 (can also be used as digital inputs)

• Analog Outputs: 1

Ambient Conditions

• Cooling: External fan

• Installation Altitude: 1,000 m

• Operation Temperature: -10 60 C (derating above 40 C)

• Storage Temperature: -40 70 C

• Max Relative Humidity: 95%

Connections

• Max Motor Cable Length: Shielded 25 m, Unshielded 50 m

Mechanical Data

• Mounting: Through-hole / wall / side-by-side

• Degree of Protection: IP20 / UL open type

• Frame Size: FSC

• Net Weight: 2.4 kg

• Dimensions: 184 182 169 mm (W H D)
