SIEMENS POWER SUPPLY 6EP1336-3BA10

About SIEMENS POWER SUPPLY 6EP1336-3BA10

SITOP PSU8200 24V DC / 20A

Article No.: 6EP1336-3BA10
Stabilized power supply

Input:

• Power supply: 1-phase or 2-phase AC/DC

• AC input voltage: 120230 V (85275 V range)

• DC input voltage: 110220 V (88350 V range)

• Line frequency: 50/60 Hz (4763 Hz)

• Input current: 120 V 4.6 A, 230 V 2.5 A

• Wide range input: Yes

• Buffering time at rated current: 20 ms

Output:

• Output voltage: 24 V DC (adjustable 2428 V via potentiometer)

• Output current: 20 A (020 A range, derating +6070 C: 3%/K)

• Residual ripple: Max 100 mV, typical 80 mV

• Peak voltage: Max 200 mV, typical 100 mV

• Response delay: Max 1.5 s

• Voltage rise time: Typical 250 ms

• Short-term overload: 60 A, 25 ms

• Constant overload (start-up): 30 A

• Number of parallel units for power increase: 2

• Efficiency: 94%

• Power loss: 31 W typical

Protection & Monitoring:

• Overvoltage protection: <31.8 V

• Short-circuit proof: Yes

• Short-circuit protection: Constant current ~21.5 A or latching shutdown

• Overcurrent/overload capability: 150% I_out for up to 5 s/min

• LED indicators: Green 24V OK, Yellow Overload, Red Latching shutdown

Safety & Isolation:

• Galvanic isolation: Input/output: Yes

• SELV output: According to EN 61204-7

• Protection class: IP20, Class I

• Max leakage current: 3.5 mA (typ. 1 mA)

EMC & Standards:

• Emitted interference: EN 55022 Class B

• Mains harmonics limitation: EN 61000-3-2

• Interference immunity: EN 61000-6-2

Approvals & Certifications:

• CE, UL, cULus (UL 508, CSA C22.2), CSA, UKCA, EAC, RCM, SEMI F47, BIS, Shipbuilding (ABS, DNV)

Ambient Conditions:

• Operating temperature: -25 +70 C (startup from -40 C)

• Storage/Transport temperature: -40 +85 C

• Environmental category: IEC 60721, Climate class 3K3, 595% humidity, no condensation

Connections:

• Input: Screw terminals, L/N/PE, 0.24 mm

• Output: Screw terminals +/-, 0.24 mm

• Auxiliary contacts (alarm/remote ON/OFF): 0.141.5 mm

Mechanical Data:

• Dimensions (W H D): 90 125 125 mm

• Installation width height: 90 225 mm

• Required spacing: Top/Bottom 50 mm, Left/Right 0 mm

• Mounting: DIN rail EN 60715 357.5/15

• Weight: 1.2 kg

• Housing: Can be lined up with multiple units
