Data sheet 6AV2124-1QC02-0AX1

SIMATIC HMI KP1500 Comfort
Comfort Panel, key operation, 15" widescreen TFT display, 16 million colors, PROFINET interface, MPI/PROFIBUS DP interface, 24 MB configuration memory, WEC 2013, configurable as of WinCC Comfort V14 SP1 with HSP, ambient temperature up to 50 C (up to 55 C with restrictions)

General Information

Product type designation: KP1500 Comfort

Display

• Design: TFT

• Screen diagonal: 15.4 in

• Display width: 331.2 mm

• Display height: 207 mm

• Colors: 16,777,216

• Resolution: 1280 800 pixels

Backlighting

• MTBF (25 C): 80,000 h

• Dimmable: Yes (LED)

Control Elements

Keyboard

• Function keys: 36

• Function keys with LEDs: 36

• Keys with LED: Yes

• System keys: Yes

• Numeric keyboard: Yes

• Alphanumeric keyboard: Yes

Touch operation: No

DP direct LEDs: 36
Direct keys: 36

Installation / Mounting

• Mounting position: Vertical

• Portrait mounting: No

• Landscape mounting: Yes

• Max inclination without external ventilation: 35

Supply Voltage

• Type: DC

• Rated value: 24 V

• Range: 19.2 V 28.8 V

Input Current

• Current consumption: 1.7 A

• Inrush It: 0.5 As

Power Consumption

• Active power: 41 W

Processor & Memory

• Processor: X86

• Flash: Yes

• RAM: Yes

• User memory: 24 MB

LEDs / Acoustics

• Info LED: No

• Power LED: No

• Error LED: No

• Buzzer: No

• Speaker: Yes

Clock

• Hardware real-time clock: Yes

• Retentive: Yes (backup approx. 6 weeks)

• Synchronizable: Yes

Interfaces

• Industrial Ethernet: 2 ports (switch) + 1 independent

• RS485: 1 (RS422/485 combined)

• USB 2.0: 2 ports

• SD card slots: 2

Supported Protocols

• PROFINET / PROFINET IO / IRT: Yes

• PROFIBUS: Yes

• MPI: Yes

• Ethernet/IP: Yes

• TCP/IP, DHCP, SNMP, DCP, LLDP: Yes

• MODBUS: Yes

• Web protocols: HTTP, HTTPS, HTML, XML, CSS, ActiveX, JavaScript

Redundancy

• MRP: Yes

EMC / Protection

• Interference emission EN 55011 Class A: Yes

• IP65 (front), IP20 (rear)

• NEMA Type 4 / 4x (front): Yes

Standards / Approvals

• CE, cULus, RCM, KC, EAC

• ATEX Zone 2 & 22

• IECEx Zone 2 & 22

• cULus Class I Zone 2

• FM Class I Div 2

(No marine approvals)

Ambient Conditions

• Indoor use: Yes

• Outdoor use: No

• Operating temp (vertical): 050 C (55 C with restrictions)

• Storage temp: 20 to 60 C

• Humidity: Max 90% (no condensation)

Operating System

• Windows Embedded Compact 2013

Configuration

Supported software:

• WinCC Comfort / Advanced / Professional (V14 SP1 HSP and higher)

Runtime Functions

• Alarm system, message buffer, recipes, variables

• Trend view, PDF viewer, HTML browser, media player

• OPC UA Client/Server

• Sm@rtServer

Peripherals

• Printer: Yes

• USB memory: Yes

• SD/MMC memory cards: Supported

• Network camera: Yes

Mechanical Data

• Front material: Aluminum

• Width: 483 mm

• Height: 310 mm

• Cutout: 450 291 mm

• Depth: 73.2 mm

• Weight: 4.7 kg
