SIEMENS PLC MODULES 6ES7288 2DR32 0AA0

The Siemens PLC Module 6ES7288-2DR32-0AA0 is a compact yet robust programmable logic controller designed for automation applications. With an operating temperature range of -20C to +60C and an impressive 95% humidity tolerance, it ensures reliable performance in challenging environments. The module is protected by an IP20-rated enclosure, safeguarding it from dust while maintaining efficient operation. Measuring 70 x 100 x 81 mm and weighing just 295.4 grams, this lightweight module is DIN-rail mounted for easy installation. Powered by a 24V DC voltage, the module operates with a rated current of 165 mA, making it energy-efficient while delivering powerful functionality. With a frequency range of 50/60 Hz, it is suitable for industrial automation systems and maintains isolation up to 500V AC for enhanced operational safety. Its sleek black design ensures it integrates seamlessly into your setup while boosting productivity through reliable automation.

General Information

• Product Type: SM DR32

• Digital Inputs: 16 DI, 24 V DC, Sink/Source

• Digital Outputs: 16 DO, Relay, 2 A

Supply Voltage

• Rated Value: 24 V DC

• Permissible Range: 20.4 28.8 V DC

• Current Consumption: Typ. 165 mA (from backplane 5 V DC)

Digital Inputs (DI)

• Number: 16 (in groups of 2)

• Parallel Switching: Yes

• Input Type: DC, IEC 61131 Type 1

• Signal Levels:

  • 0: < 5 V DC

  • 1: +15 to +30 V DC

• Input Current (typ): 4 mA (1), 1 mA max (0)

• Input Delay: 200 s (01 and 10)

• Cable Length: Max 500 m (shielded), 300 m (unshielded)

Digital Outputs (DO)

• Number: 16

• Output Type: Relay

• Short-Circuit Protection: No

• Rated Current: 2 A per output

• Output Delay: 10 ms (01 and 10)

• Switching Capacity:

  • Resistive: 2 A (up to 60 C)

  • Inductive: 2 A

  • Lamp Load: 30 W DC / 200 W AC

• Cable Length: Max 500 m (shielded), 150 m (unshielded)

Relay Outputs

• Number: 16

• Rated Supply Voltage: 24 V DC

• Reverse Polarity Protection: Yes

• Coil Current (max): 165 mA

Diagnostics & Status

• LED Indicators: Inputs status, Outputs status

Isolation & Potential Separation

• DI Channels: Optocoupler

• DO Channels: Relay dry contact

• Isolation Tested:

  • Input: 500 V AC, 1 min

  • Output: 1500 V AC, 1 min

EMC / Interference Immunity

• ESD: 4 kV contact, 8 kV air (IEC 61000-4-2)

• RF Radiation: 801000 MHz: 10 V/m, 1.42.0 GHz: 3 V/m, 2.02.7 GHz: 1 V/m

• Cable-Borne Interference: 2 kV (IEC 61000-4-4)

• Voltage Surge: 2 kV supply lines, 2 kV signal cables

• High-Frequency Conducted Disturbance: 10 V/m, 80% AM at 1 kHz

• Emission of Radio Interference: EN 55011, Class A, Group 1

Protection & Standards

• IP Rating: IP20

• CE Mark: Yes

Dimensions & Weight

• Width: 70 mm

• Height: 100 mm

• Depth: 81 mm

• Weight: 295.4 g
